bedra5800
Regular Brass
Characteristics:
bedra5800 is a copper-zinc alloy brass, characterized by its lead-free composition and good machinability. It is primarily used as a cost-effective replacement for conventional lead-containing machining brasses, especially in applications where high mechanical properties and corrosion resistance are not critical.
Typical applications:
It can be applied to all deep drawing and bending stressed parts, such as pins, rivets, washers, nuts, conduits, barometer springs, screens, radiator parts, and others.
Standardization and composition
| UNS | C28500 |
|---|---|
| EN | CuZn42 (CW510L) |
| JIS | / |
| GB | T28200 (H59) |
| Cu | 57-59% |
| Pb | ≤ 0.1% |
| Sn | ≤ 0.3% |
| Al | ≤ 0.05% |
| Fe | ≤ 0.3% |
| Ni | ≤ 0.3% |
| Zn | balance% |
Physical Properties ①
Note①：The testing temperature is 20℃. Note②：The testing temperature range is 20℃ to 300℃.
| Density (g/cm³) | 8.4 |
|---|---|
| Metling temperature (℃) | 899 |
| Electrical conductivity (%IACS) | 23 |
| Thermal conductivity (W / m x K) | 100.4 |
| Coefficient of thermal expansion② (10-6/K) | 20.5 |
| Modulus of elasticity (GPa) | 105 |
Fabrication Properties
Note③：C37700 = 100% Note④：C36000 = 100%
| Cold workability | Fair |
| Hot workability | Excellent |
| Brazing | Excellent |
| Resistance welding | Good |
| Forgeability rating ③ | 100% |
| Machinability rating④ | 60% |
Mechanical Properties
| Temper | Diameter(mm) | Tensile Strength(MPa min.) | Yield Strength(MPa min.) | Elongation(% min.) | Hardness(HBW min.) |
|---|---|---|---|---|---|
| R360 | 6.0 ≤ Φ ≤ 80 | 360 | max. 320 | 20 | 90 |
| R430 | 2.0 ≤ Φ ≤ 40 | 430 | 220 | 10 | 110 |
| R500 | 2.0 ≤ Φ ≤ 14 | 500 | 350 | 5 | 135 |
Dimension Tolerance and Delivery Form
Note⑥：The tolerances listed in the table are specified as all plus or all minus. When tolerances are specified as plus and minus (±), half the values given.
| Straight bar | Coil wire | |||||
| Diameter (mm) | Tolerance⑥ (mm) | Ovality (mm) | Length (mm. max.) | Straightness (mm/m max.) | ID (mm) | Weight (kg) |
| 3.0 ≤ Φ < 6.0 | 0.02 | 0.010 | 2500 | 1.0 | 600 | 500 |
| 6.0 ≤ Φ < 10 | 0.03 | 0.015 | 3600 | 1.0 | 650 | 50 |
| 10 ≤ Φ < 18 | 0.04 | 0.020 | 3600 | 1.0 | 1200 | 500 |
| 18 ≤ Φ < 25 | 0.06 | 0.030 | 3660 | 1.0 | ||
| 25 ≤ Φ < 40 | 0.10 | 0.050 | 3660 | 1.0 | ||
| 40 ≤ Φ < 60 | 0.15 | 0.075 | 3660 | 1.0 | ||
| 60 ≤ Φ ≤ 80 | 0.30 | 0.150 | 3000 | 1.0 |
Other Delivery Forms
Profiles
