bedra49250
Bismuth Brass
Characteristics：
The alloy exhibits excellent turning performance comparable to that of C3604, as well as superior riveting and hot forging capabilities. Additionally, it possesses outstanding mechanical and electrical properties, making it an ideal material to replace lead brass. The alloy is strictly lead-free according to RoHS and ELV.
Typical applications:
Primarily serving as a lead-free substitute for leaded brass, this alloy finds extensive applications in e-cigarettes, connectors, valve cores, embedded nuts, smart charging systems, coffee pot components, consumer electronics, hardware, machinery, construction equipment, 5G accessories, and more.
Standardization and composition
| UNS | C49250 |
|---|---|
| EN | / |
| JIS | C6801 |
| GB | T49240 (HBi60-1.3) T49360 (HBi59-1) T49210 (HBi58-1.5) |
| Cu | 57.0-64.0 % |
| Pb | ＜ 0.009 % |
| Bi | 0.5-4.0 % |
| Sn | 0.05-1.2 % |
| Zn | Balance % |
Physical properties①
Note①：The testing temperature is 20℃. Note②：The testing temperature range is 20℃ to 300℃.
| Density (g/cm³) | 8.41 |
|---|---|
| Electrical conductivity (%IACS) | 24 |
| Thermal conductivity (W / m x K) | 96 |
| Coefficient of thermal expansion② (10-6/K) | 18.9 |
| Modulus of elasticity (GPa) | 100.7 |
Fabrication Properties
Note③：C36000 = 100%
| Capacity for being cold worked | Fair |
| Capacity for being hot formed | Fair |
| Brazing | Good |
| Resistance welding | Not recommended |
| Forgeability | Good |
| Machinability rating③ | 95% |
Mechanical Properties④
Note④：bedra technical standards
| Temper | Diameter (mm) | Tensile Strength (MPa min.) | Yield Strength (MPa min.) | Elongation (A% min.) | Hardness (HV5 min.) |
|---|---|---|---|---|---|
| H02 | Ф ＜ 3.0 | 420 | 170 | 2 | 120 |
| H02 | 3 ≤ Ф ＜ 25 | 420 | 170 | 7 | 120 |
| H02 | 25 ≤ Ф ＜ 80 | 390 | 140 | 15 | 100 |
| H04 | Ф ＜ 3.0 | 500 | 350 | 1 | 140 |
| H04 | 3.0 ≤ Ф ≤ 12 | 500 | 350 | 5 | 140 |
Dimension Tolerance and Delivery Forms
Note⑤：The tolerances listed in the table are specified as all plus or all minus. When tolerances are specified as plus and minus (±), half the values given.
| Straight bar | Coil wire | |||||
| Diamter (mm) | Tolerance⑤ (mm) | Ovality (mm max.) | Length (mm. max.) | Straightness (mm/m max.) | ID (mm) | Weight(kg） |
| 1.5 ≤ Ф ＜3.0 | 0.02 | 0.010 | 3600 | 0.5 | 500 | 50 |
| 3.0 ≤ Ф ＜6.0 | 0.02 | 0.010 | 3600 | 0.5 | 800 | 500 |
| 6.0 ≤ Ф ＜10 | 0.03 | 0.015 | 3600 | 0.5 | 1200 | 800 |
| 10 ≤ Ф ＜18 | 0.04 | 0.020 | 3600 | 0.5 | 1500 | 1000 |
| 18 ≤ Ф ＜25 | 0.06 | 0.030 | 4000 | 0.5 | / | / |
| 25 ≤ Ф ＜40 | 0.10 | 0.050 | 4000 | 0.5 | / | / |
| 40 ≤ Ф ＜60 | 0.15 | 0.075 | 4000 | 0.5 | / | / |
| 60 ≤ Ф ≤ 80 | 0.30 | 0.150 | 3000 | 2.0 | / | / |
Other Delivery Forms
Tubes, Profiles
